COM Express Type 7 Starter Kit Plus COM Express Type 7 模块化电脑开发套件
主要特点Express-BASE7 Reference Carrier Board
Debug Card (DB40) and necessary cabling, power supplyADLINK USB stick with carrier board schematic, drivers, BSP, LibrariesADLINK Live Linux USB stick with SEMA pre-installed10GbE adapter card (fiber or copper
主要特点
-
Express-BASE7 Reference Carrier Board
-
Debug Card (DB40) and necessary cabling, power supply
-
ADLINK USB stick with carrier board schematic, drivers, BSP, Libraries
-
ADLINK Live Linux USB stick with SEMA pre-installed
-
10GbE adapter card (fiber or copper type by choice)
-
COM Express Type7 module, user manual (
